Roller autofeeder hydraulic cutting machine
Application:
The machine is mainly suitable for cutting materials needed cutting out like epe eva foam, blister plastic, scouring pad, kitchen sponge APET, leather plastic, fiberglass and cork, especially for the whole sheer or whole roll material.
Features:
1, Easy-handle, low failure rate fast cutting
2, Dual cylinders and precise4-column automatic equilibrium joint structure, which can guarantee the same cutting depth each cutting position
3, Furnished with autofeeder,2-3times production efficiency can be improved.
4, PLC eytem makes the function and performance of the machine more perfect and more humane.
5, Centralized lubricating system guarantees the precision of the machine and makes the machine durable.
Spencification
Model | Cutting Force(T) | Stroke(mm) | Motor power(kw) | Cutting Area(L*W,mm) | Dimension(L*W*H)(mm) | NM(kg) |
WZ-4012ATR | 40 | 50-250 | 3 | 1200*600 | 2000*1200*1500 | 2100 |
WZ-4016ATR | 40 | 50-250 | 3 | 1600*600 | 2400*1200*1500 | 2550 |
WZ-6012ATR | 60 | 50-250 | 4 | 1200*700 | 2050*1300*1500 | 2650 |
WZ-6016 ATR | 60 | 50-250 | 4 | 1600*700 | 2450*1300*1500 | 3100 |
WZ-8012ATR | 80 | 50-250 | 5.5 | 1200*800 | 2180*1400*1500 | 4100 |
WZ-8016ATR | 80 | 50-250 | 5.5 | 1600*800 | 2580*1400*1500 | 4400 |
WZ-10012ATR | 100 | 50-250 | 7.5 | 1200*900 | 2280*1500*1500 | 4800 |
WZ-10016ATR | 100 | 50-250 | 7.5 | 1600*900 | 2680*1500*1500 | 5700 |
|
|
